Zoom H8 Handy Recorder
Hersteller: Zoom
Weitere Informationen:
https://www.zoom-na.com/products/field-video-recording/field-recording/zoom-h8-handy-recorder#overview
287,00 CHF
Produktbeschreibung
an Lager (5.2.2025)
The Only Recorder That Adapts To Your Way Of Creating
12 simultaneous recording tracks, interchangeable capsules, and an App-driven touchscreen interface, the H8 is designed to meet all your audio recording needs.
Features
There’s An App For Your Workflow
Whether you’re capturing audio on location, recording music, or producing a podcast, the H8 color touchscreen adapts to your project's needs with three App-driven interface options. All with the touch of your finger.
The Podcast App
The PODCAST App makes producing your podcast simple. With dedicated Sound Pads, use the touch screen to trigger sound effects, music beds and more. Choose from 13 high quality sounds or load your own via an SD card.
The Podcast App accommodates up to 4 mics and two Sound Pad channels.
The Music App
The MUSIC App puts all the important controls at your fingertips: audio levels, faders, metering and more. With 10 inputs and 12 tracks, capturing a large group is easy. Mix, overdub, and enhance your recordings with EQ and compression. Connect to Zoom’s Guitar Lab via USB to access an endless assortment of amps and effects
The Field App
The FIELD App is ideal for location sound, sound design, conferences, and more. It gives you instant access to large meters for every track, so you can make sure your recordings never clip. Adjust input type, lo-cut, compression, limiter, noise gate, and other key settings.
The Mic Capsule
The H8 comes with the Zoom XYH-6 microphone. This capsule provides two matched high-quality unidirectional mics, for capturing signal directly in front of the recorder. With the Zoom mic capsule system you can easily swap capsules to ensure you’re always using the right mic for the job.
Six interchangeable mic capsules that can be swapped out as easily as the lesn of a camera
Inputs & Outputs
H8 offers 4 XLR inputs with dedicated pad switches and gain control. 2 additional XLR/TRS combo jacks with Hi-Z switches allow you to capture line level signals, microphones, or directly record electric guitars and basses.
Monitor tracks using the built-in 1/8” headphone output or connect directly to your camera using the dedicated stereo line output.
Multi-Channel Audio Interface
The H8 is a powerful USB audio interface. Connect via USB to your PC, Mac, iPad or tablet for up to 12 channels of simultaneous recording.
Recording Time & File Formats
Get more than 15 hours of recording time from just 4 AA batteries. Or record forever with the optional AD-17 adapter.
The H8 records BWF-compliant WAV and MP3 files in any of the following formats:
State-of-the-Art Editing
The Zoom H8 comes with a free download license for Cubase LE and Steinberg’s WaveLab Cast software. WaveLab Cast helps you to finalize your project with a wide range of comprehensive editing, mixing, and refinement tools.
Podcasting
WaveLab Cast connects you directly with podcast directories, such as Spreaker or Podbean*. You can upload episodes quickly, plus directly create and publish RSS feeds.
Audio for Video
Import your video file and WaveLab Cast will automatically extract the audio. You can use the editing tools to lower unwanted noise, change levels and remove loud sibilants. Metering options allow you to build new tracks, fade-in your music, use EQ and compression. Re-attach the audio to the video file using WaveLab Cast’s export functions.
Field Recording
WaveLab Cast supports up to 96KHz audio quality and includes a high-end re-sampler. RestoreRig removes noise and unwanted sounds. You can assemble new files using the snap functions and crossfade options. Once you’re done, export your sound files in any popular audio format.
Here's what comes in the package:
Main Specifications
Number of input channels: 8 (XY mic capsule, 1-4, A, B)
Number of output channels: 1 (combined stereo headphone/line)
Connectors
Note: Use a USB cable that supports data transfer. Operation using USB bus power is possible.
Audio interface
Display: 2.4" (320×240) full-color touchscreen LCD
Power:
Note: When using a USB cable designed for recharging, audio interface, SD card reader and Guitar Lab connection functions cannot be used.
The Only Recorder That Adapts To Your Way Of Creating
12 simultaneous recording tracks, interchangeable capsules, and an App-driven touchscreen interface, the H8 is designed to meet all your audio recording needs.
Features
- Customized applications for field recording, music and podcasting
- 3 distinct interfaces for field recording, music and podcasting
- Interchangeable input capsules
- 12-track simultaneous recording
- Four mic inputs and two XLR/TRS combo connectors
- Gain control knobs and -20dB pads for each input
- Supplied XYH-6 X/Y capsule provides secondary input via a stereo ⅛” Mic/Line In mini phone jack
- Phantom power for all six XLR mic inputs: +24/+48V
- Large color LCD touchscreen display
- Records directly to SD, SDHC and SDXC cards up to 512GB
- Up to 24-bit /96kHz audio in BWF-compliant WAV or a variety of MP3 formats
- Auto-record, Pre-record and Backup-record functions mean that you'll never miss that perfect take
- Built-in effects, including low-cut filtering, compression, and limiting
- Multichannel and stereo USB audio interface for PC/Mac/iPad
- Accepts standard AA alkaline or NiMH rechargeable batteries
- Over 15 hours of operation with 4 AA alkaline batteries
There’s An App For Your Workflow
Whether you’re capturing audio on location, recording music, or producing a podcast, the H8 color touchscreen adapts to your project's needs with three App-driven interface options. All with the touch of your finger.
The Podcast App
The PODCAST App makes producing your podcast simple. With dedicated Sound Pads, use the touch screen to trigger sound effects, music beds and more. Choose from 13 high quality sounds or load your own via an SD card.
The Podcast App accommodates up to 4 mics and two Sound Pad channels.
The Music App
The MUSIC App puts all the important controls at your fingertips: audio levels, faders, metering and more. With 10 inputs and 12 tracks, capturing a large group is easy. Mix, overdub, and enhance your recordings with EQ and compression. Connect to Zoom’s Guitar Lab via USB to access an endless assortment of amps and effects
The Field App
The FIELD App is ideal for location sound, sound design, conferences, and more. It gives you instant access to large meters for every track, so you can make sure your recordings never clip. Adjust input type, lo-cut, compression, limiter, noise gate, and other key settings.
The Mic Capsule
The H8 comes with the Zoom XYH-6 microphone. This capsule provides two matched high-quality unidirectional mics, for capturing signal directly in front of the recorder. With the Zoom mic capsule system you can easily swap capsules to ensure you’re always using the right mic for the job.
Six interchangeable mic capsules that can be swapped out as easily as the lesn of a camera
Inputs & Outputs
H8 offers 4 XLR inputs with dedicated pad switches and gain control. 2 additional XLR/TRS combo jacks with Hi-Z switches allow you to capture line level signals, microphones, or directly record electric guitars and basses.
Monitor tracks using the built-in 1/8” headphone output or connect directly to your camera using the dedicated stereo line output.
Multi-Channel Audio Interface
The H8 is a powerful USB audio interface. Connect via USB to your PC, Mac, iPad or tablet for up to 12 channels of simultaneous recording.
Recording Time & File Formats
Get more than 15 hours of recording time from just 4 AA batteries. Or record forever with the optional AD-17 adapter.
The H8 records BWF-compliant WAV and MP3 files in any of the following formats:
State-of-the-Art Editing
The Zoom H8 comes with a free download license for Cubase LE and Steinberg’s WaveLab Cast software. WaveLab Cast helps you to finalize your project with a wide range of comprehensive editing, mixing, and refinement tools.
Podcasting
WaveLab Cast connects you directly with podcast directories, such as Spreaker or Podbean*. You can upload episodes quickly, plus directly create and publish RSS feeds.
Audio for Video
Import your video file and WaveLab Cast will automatically extract the audio. You can use the editing tools to lower unwanted noise, change levels and remove loud sibilants. Metering options allow you to build new tracks, fade-in your music, use EQ and compression. Re-attach the audio to the video file using WaveLab Cast’s export functions.
Field Recording
WaveLab Cast supports up to 96KHz audio quality and includes a high-end re-sampler. RestoreRig removes noise and unwanted sounds. You can assemble new files using the snap functions and crossfade options. Once you’re done, export your sound files in any popular audio format.
Here's what comes in the package:
- H8 Handy Recorder
- XYH-6 X/Y Mic Capsule
- AA Batteries (x4)
- Quick Guide
Main Specifications
Number of input channels: 8 (XY mic capsule, 1-4, A, B)
Number of output channels: 1 (combined stereo headphone/line)
Connectors
- MIC IN: ZOOM mic connector
- INPUT 1-4: XLR jacks (2: HOT)
- INPUT A/B: XLR/TRS combo jacks (XLR: 2 hot, TRS: TIP hot)
- USB: USB Micro-B
Note: Use a USB cable that supports data transfer. Operation using USB bus power is possible.
- REMOTE: ZOOM BTA-1 or other dedicated wireless adapter
- LINE OUT: 3.5 mm stereo mini
- PHONE OUT: 3.5 mm stereo mini
- +24 V/+48 V (independent ON/OFF for INPUTS 1–4, Aand B)
- Recording media: Cards that support SD/SDHC/SDXC specifications
- WAV: 44.1/48/96 kHz, 16/24-bit, mono/stereo
- MP3: 128, 192, 320 kbps
Audio interface
- Multitrack mode: 44.1/48/96 kHz, 16/24-bit, 12-in/2-out
- Stereo mix mode: 44.1/48 kHz, 24-bit, 2-in/2-out
- Chromatic/Guitar/Bass/Open A/Open D/Open E/Open G/DADGAD
Display: 2.4" (320×240) full-color touchscreen LCD
Power:
- 4 AA batteries (alkaline, NiMH or lithium)
- AC adapter (ZOOM AD-17): DC 5 V/1A
- USB bus power
- H8: 116.4 mm (W) × 163.3 mm (D) × 48.6 mm (H)
- XYH-6: 78.9 mm (W) × 60.2 mm (D) × 45.2 mm (H)
- H8: 354 g
- XYH-6: 130 g
Note: When using a USB cable designed for recharging, audio interface, SD card reader and Guitar Lab connection functions cannot be used.
Weitere Informationen: https://www.zoom-na.com/products/field-video-recording/field-recording/zoom-h8-handy-recorder#overview
